Laboratories


Sl.No
Equipment List
1 Regulated Power Supply
2 Function Generator
3 Single Phase Energy Meter
4 Oscilloscope (20 MHz)
5 Digital Storage Oscilloscope (20 MHz)
6 AC/DC – Voltmeters (cy)
7 AC/DC Ammeters (sal)
8 Multi-meters (sq)
9 Single Phase Wattmeter
10 Decade Resistance Box
11 Decade Inductance Box
12 Decade Capacitance Box
13 Circuit Connection Boards
Sl.No
Equipment List
1 Transfer Function of DC Servo Motorr
2 Process Control Simulator
3 AC Servo Position Control System
4 Stepper Motor Controller with Motor
5 Transfer Function of Two Phase AC servo motor
6 DC Motor & DC Generator Transfer function Study trainer (cy)
7 DC Motor Generator Load Test Module
8 DC Motor Load Test module
9 DC Motor Position Control System
10 Synchro Transmitter and Receiver
11 Analog to Digital Converter
12 Digital to Analog Converter
13 Single Phase Energy Meter Calibration Setup
14 Current Transformer Calibration Setup
15 Power and Power factor Measurement Setup
16 LVDT
17 Maxwell’s Inductance Bridge
18 Schering Bridge
19 Wheatstone Bridge
20 Kelvin’s Double Bridge
21 Instrumentation Amplifier
22 Pressure Measurement Trainer
23 Decade Inductance Box
24 Decade Capacitance Box
25 Decade Resistance Box
26 Series AC and DC Trainer
27 Temperature Measurement trainer using RTD, Thermistor Sensor
28 Optical Sensor Trainer
29 Strain measurement Module
30 Flow Measurement Trainer
Sl.No
Equipment List
1 Personal computers
2 1KW PV panels
3 Battery storage system with charge and discharge control
4 PV Emulator
5 Micro Wind Energy Generator module
6 1 KW Solar PV training system (cy)
7 Wind-Solar Hybrid Power system with micro wind energy generator(sal)
Sl.No
Equipment List
1 DC Shunt Motor
2 DC Compound Motor
3 DC Series Motor
4 DC Shunt Motor # DC Shunt Generator
5 DC Shunt Motor # DC Compound Generator
6 DC Shunt Motor # Alternator (cy)
7 DC Shunt Motor # Alternator(sal)
8 3 Ph Induction Motor (sq)
9 3 Ph Induction Motor (slip)
10 1 Ph Induction Motor
11 Synchronous Motor
12 1 Ph Transformer
13 3 Ph Transformer
14 1 Ph Auto Transformer
15 1 Ph Transformer
16 3 AutroPh Transformer
17 1 Ph Resistive Load
18 1 Ph Lamp Load
19 3 Ph Lamp Load
20 3Ph Resistive Load
21 3Ph InductiveLoad
22 Rheostates
Sl.No
Equipment List
1 DC Shunt Motor
2 DC Compound Motor
3 DC Series Motor
4 DC Shunt Motor # DC Shunt Generator
5 DC Shunt Motor # DC Compound Generator
6 DC Shunt Motor # Alternator (cy)
7 DC Shunt Motor # Alternator(sal)
8 3 Ph Induction Motor (sq)
9 3 Ph Induction Motor (slip)
10 1 Ph Induction Motor
11 Synchronous Motor
12 1 Ph Transformer
13 3 Ph Transformer
14 1 Ph Auto Transformer
15 3Ph Auto Transformer
16 3Ph InductiveLoad
17 1 Ph Resistive Load
18 1 Ph Lamp Load
19 3 Ph Lamp Load
20 3Ph Resistive Load
